Freescale Semiconductor MPC8533EVTANG
| Parameters | |
|---|---|
| Series | MPC85xx |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| RoHS Status | ROHS3 Compliant |
| Package / Case | 783-BBGA, FCBGA |
| Mfr | Freescale Semiconductor |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C ~ 90°C (TA) |
| Supplier Device Package | 783-FCPBGA (29x29) |
| Speed | 800MHz |
| Ethernet | 10/100/1000Mbps (2) |
| USB | - |
| SATA | - |
| Core Processor | PowerPC e500v2 |
| Voltage - I/O | 1.8V, 2.5V, 3.3V |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Graphics Acceleration | No |
| RAM Controllers | DDR, DDR2 |
| Co-Processors/DSP | Security; SEC |
| Security Features | Cryptography, Random Number Generator |
| Display & Interface Controllers | - |
| Additional Interfaces | DUART, HSSI, I²C, PCI |
| Package | Bulk |
| Product Status | Active |
| Base Product Number | MPC85 |
| REACH Status | Vendor Undefined |
| Standard Package | 1 |
| ECCN | 5A002A1 FRE |
| HTSUS | 8542.31.0001 |
The MPC8533EVTANG is an integrated processor from Freescale Semiconductor (now part of NXP Semiconductors). It belongs to the PowerQUICC III family, specifically the MPC8533E variant. This processor is designed for embedded applications, offering high performance and flexibility. With a 32-bit core based on Power Architecture technology, it comes with enhanced features such as 32-Kbyte L1 instruction and data caches, and supports a wide range of operating conditions.
MPC8533EVTANG Features
The MPC8533EVTANG boasts a range of impressive features that make it suitable for demanding embedded applications. It includes:
1. A high-performance 32-bit core with 32-Kbyte L1 instruction and data caches, providing robust processing power.
2. An auxiliary processing unit (SPE APU) that offers an extended instruction set for vector (64-bit) integer and fractional operations, enhancing signal processing capabilities.
3. A memory management unit (MMU) specifically designed for embedded applications, supporting page sizes from 4-Kbyte to 4-Gbyte.
4. A 256-Kbyte L2 cache or SRAM with full ECC (error correction code) support, ensuring data integrity.
5. A programmable interrupt controller (PIC) compliant with the OpenPIC architecture, supporting multiple interrupts and processor task priorities.
6. An integrated security engine optimized for algorithms related to IPSec, IKE, WTLS/WAP, SSL/TLS, and 3GPP, providing enhanced security features.
MPC8533EVTANG Applications
The Freescale Semiconductor MPC8533EVTANG is a versatile and powerful integrated processor suitable for a wide range of embedded applications. Its advanced features and flexible design make it an excellent choice for developers looking to build high-performance and reliable embedded systems. These include, but are not limited to:
· Networking equipment: Leveraging its high-speed interfaces and processing power, the MPC8533EVTANG is ideal for routers, switches, and other networking devices.
· Industrial control systems: Its robustness and reliability make it suitable for industrial automation and control applications.
· Telecommunications equipment: With support for a wide range of communication protocols and interfaces, the MPC8533EVTANG is used in base stations, gateways, and other telecommunications infrastructure.
· Multimedia devices: Its signal processing capabilities and support for high-speed memory interfaces make it suitable for audio and video processing in multimedia devices.
